See Mirror image
House with attic in modern style with usable area 182,81 m2. House with a large garage. Minimum size of a plot needed for building a house is 25,85x30,35 m.
Author:
mgr inż. arch. LESZEK KALANDYK
| 1. Usable area | 182,81 m² |
| 2. Area garage | 38,66 m² |
| 3. Additional area | 19,69 m² |
| 4. Total surface | 495,68 m² |
| 5. Building area | 247 m² |
| 6. Net volume | 875 m³ |
| 7. Gross volume | 1584 m³ |
| 8. Energy for heating | 10,56 kWh/m²*year |
| 9. Building height | 8,88 m |
| 10. Attic wall height | 1 m |
| 11. Roof angle | 43 ° |
| 12. Roof area | 441,96 m² |
| 13. Сeiling height | 2,70/3,20 m |
| 14. Minimum plot size | 25,85 x 30,35 m |
| 1. Foundation footings | ferroconcrete |
| 2. Foundation walls | hollow bricks made of concrete |
| 3. Exterior walls | made of ceramic hollow bricks Heluz Family with a thickness of 50 cm |
| 4. Interior walls | of ceramic hollow bricks Heluz Family with thickness of 25 cm, 11,5 cm |
| 5. Ceiling | ferroconcrete, made of reinforced concrete |
| 6. Roof construction | wooden |
| 7. Roofing | ceramic roof tile Koramic plain tile by Wienerberger |
| 8. Facade | finished with silicone plaster, pedestal clad with cut sandstone |
| 9. Windows and doors | PVC by Oknoplast, garage doors by Hormann |
| 10. Type of heating | gas boiler |
| 11. Ventilation | mechanical with recuperation |
Ground floor
| Usable area | 108,69 m2 |
| 1. Lobby | 12,09 m2 |
| 2. Hall | 12,61 m2 |
| 3. Pantry | 1,18 m2 |
| 4. Kitchen | 15,58 m2 |
| 5. Living room with dining area | 45,66 m2 |
| 6. Bedroom | 16,43 m2 |
| 7. Bathroom | 5,14 m2 |
| 8. Boiler room | 6,27 m2 |
| 9. Garage | 38,66 m2 |
Attic
| Usable area | 74,12 (107,7) m2 |
| 1. Hall | (7,74) 7,74 m2 |
| 2. Bathroom | (15,90) 10,12 m2 |
| 3. Bedroom | (26,07) 20,05 m2 |
| 4. Bedroom 2 | (25,79) 19,77 m2 |
| 5. Laundry room | (15,90) 10,12 m2 |
| 6. Wardrobe | (16,30) 6,32 m2 |
| 7. Attic space | (35,72) 13,02 m2 |
| 8. Attic space 2 | (14,02) 0,40 m2 |
What does the project contain?
Finished project is a documentation, consisting of 3 copies of architectural and construction design and technical design. It is made by authorized designers in accordance with the current rules of construction art and the latest provisions of the Construction Law.
Read more on the What does the project contain?
