Hit
See Mirror image
Two storey house in modern style with usable area 171,31 m2. House with a large garage. Minimum size of a plot needed for building a house is 24x28,25 m.
Author:
mgr inż. arch. LESZEK KALANDYK
| 1. Usable area | 171,31 m² |
| 2. Area garage | 36,36 m² |
| 3. Additional area | 6,1 m² |
| 4. Total surface | 392 m² |
| 5. Building area | 271 m² |
| 6. Net volume | 625,1 m³ |
| 7. Gross volume | 1180 m³ |
| 8. Energy for heating | 16,57 kWh/m²*year |
| 9. Building height | 10,35 m |
| 10. Roof angle | 35 ° |
| 11. Roof area | 54,58 m² |
| 12. Сeiling height | 2,97/2,80/2,94 m |
| 13. Minimum plot size | 24 x 28,25 m |
| 1. Foundation footings | made of reinforced concrete |
| 2. Foundation walls | of 24 cm and 30 cm thick flooded concrete blocks |
| 3. Exterior walls | made of Ytong Energo aerated concrete blocks with a thickness of 48cm |
| 4. Interior walls | made of 24 and 12 cm thick Silka E blocks |
| 5. Ceiling | made of reinforced concrete, slab-on-grade |
| 6. Roof construction | wooden, insulated with mineral wool of the firm Rockwool with a thickness of 23 cm, timber structure of the roof: full with a traditional arrangement of layers |
| 7. Roofing | titanium-zinc sheet metal. |
| 8. Facade | finished with silicone plaster, stone lining |
| 9. Windows and doors | aluminum |
| 10. Type of heating | gas boiler, floor heating |
| 11. Ventilation | mechanical with recuperation |
Ground floor
| Usable area | 75,31 m2 |
| 1. Hall | 13,58 m2 |
| 2. Storeroom | 1,48 m2 |
| 3. Kitchen | 14,6 m2 |
| 4. Living room | 28,57 m2 |
| 5. Canteen | 14,54 m2 |
| 6. Restroom | 2,56 m2 |
| 7. Boiler room | 6,1 m2 |
| 8. Garage | 36,36 m2 |
Floor
| Usable area | 96 m2 |
| 1. Corridor | 10,82 m2 |
| 2. Bathroom | 14,48 m2 |
| 3. Laundry regenerative | 10 m2 |
| 4. Bedroom | 18 m2 |
| 5. Wardrobe | 9,96 m2 |
| 6. Bedroom 2 | 16,58 m2 |
| 7. Bedroom 3 | 16,16 m2 |
What does the project contain?
Finished project is a documentation, consisting of 3 copies of architectural and construction design and technical design. It is made by authorized designers in accordance with the current rules of construction art and the latest provisions of the Construction Law.
Read more on the What does the project contain?
