House with attic in modern style with usable area 221,94 m2. House with a large garage. Minimum size of a plot needed for building a house is 30,22x30,97 m.
Author:
mgr inż. arch. LESZEK KALANDYK
| 1. Usable area | 221,94 m² |
| 2. Area garage | 45,76 m² |
| 3. Additional area | 1,63 m² |
| 4. Total surface | 446,29 m² |
| 5. Building area | 229,99 m² |
| 6. Net volume | 839,1 m³ |
| 7. Gross volume | 1467,85 m³ |
| 8. Energy for heating | 18,61 kWh/m²*year |
| 9. Building height | 8,76/7,66 m |
| 10. Attic wall height | 1 m |
| 11. Roof angle | 30/60/38 ° |
| 12. Roof area | 381,89 m² |
| 13. Сeiling height | 2,69/2,70/2,54 m |
| 14. Minimum plot size | 30,22 x 30,97 m |
| 1. Foundation footings | ferroconcrete |
| 2. Foundation walls | concrete |
| 3. Exterior walls | Porotherm 30 P+W ceramic hollow bricks from Wienerberger firm insulated with 20 cm thick Termo Organika styrofoam |
| 4. Interior walls | from Porotherm ceramic hollow bricks with a thickness of 25, 11.5 of the firm Wienerberger |
| 5. Ceiling | reinforced concrete, made of reinforced concrete |
| 6. Roof construction | wooden roof, mansard roof |
| 7. Roofing | semi-circular Koramic ceramic roof tile by Wienerberger |
| 8. Facade | finished with silicone plaster |
| 9. Windows and doors | PVC by Oknoplast, garage doors by Hormann |
| 10. Type of heating | gas boiler, floor heating |
| 11. Ventilation | mechanical with recuperation |
Ground floor
| Usable area | 111,11 m2 |
| 1. Lobby | 7,09 m2 |
| 2. Hall | 13,69 m2 |
| 3. Wardrobe | 2,44 m2 |
| 4. Kitchen | 8,5 m2 |
| 5. Canteen | 20,07 m2 |
| 6. Living room | 25,33 m2 |
| 7. Bedroom | 13,45 m2 |
| 8. Bathroom | 3,77 m2 |
| 9. Pantry | 1,63 m2 |
| 10. Boiler room with laundry room | 15,14 m2 |
| 11. Garage | 45,76 m2 |
Attic
| Usable area | 110,83 (134,81) m2 |
| 1. Hall | (13,04) 11,79 m2 |
| 2. Bathroom | (13,45) 10,57 m2 |
| 3. Bedroom | (23,73) 20,36 m2 |
| 4. Bedroom 2 | (24,01) 20,64 m2 |
| 5. Wardrobe | (13,19) 10,30 m2 |
| 6. Restroom | (47,39) 37,17 m2 |
What does the project contain?
Finished project is a documentation, consisting of 3 copies of architectural and construction design and technical design. It is made by authorized designers in accordance with the current rules of construction art and the latest provisions of the Construction Law.
Read more on the What does the project contain?
Recently viewed projects
221,94 + 47,39 m²
5,630 ZŁ
- Usable area 221,94 m²
- Area garage 45,76 m²
- Additional area 1,63 m²
- Total surface 446,29 m²
- Building area 229,99 m²
- Foundation footings ferroconcrete
- Foundation walls concrete
- Exterior walls Porotherm 30 P+W ceramic hollow bricks from Wienerberger firm insulated with 20 cm thick Termo Organika styrofoam
- Interior walls from Porotherm ceramic hollow bricks with a thickness of 25, 11.5 of the firm Wienerberger
- Ceiling reinforced concrete, made of reinforced concrete
