See Mirror image
House with attic in traditional style with usable area 173,02 m2. House with a large garage. Minimum size of a plot needed for building a house is 18,75x31,06 m.
Author:
mgr inż. arch. LESZEK KALANDYK
mgr inż. arch. NATALIA KOZIOŁ
| 1. Usable area | 173,02 m² |
| 2. Area garage | 39,87 m² |
| 3. Additional area | 48,41 m² |
| 4. Total surface | 409,1 m² |
| 5. Building area | 205,38 m² |
| 6. Net volume | 801,15 m³ |
| 7. Gross volume | 1062,2 m³ |
| 8. Energy for heating | 11,96 kWh/m²*year |
| 9. Building height | 8,36 m |
| 10. Roof angle | 43 ° |
| 11. Roof area | 335 m² |
| 12. Сeiling height | 2,65/2,7 m |
| 13. Minimum plot size | 18,75 x 31,06 m |
| 1. Foundation footings | ferroconcrete |
| 2. Foundation walls | concrete, thickness 30 cm |
| 3. Exterior walls | made of Ytong Energo aerated concrete blocks, thickness 40 cm |
| 4. Interior walls | made of YTONG cellular concrete blocks with a thickness of 24 cm, and Silka blocks by Xella company with a thickness of 18 and 12 cm |
| 5. Ceiling | ferroconcrete |
| 6. Roof construction | wooden, insulated with mineral wool with a thickness of 30 cm by the firm Rockwool |
| 7. Roofing | Koramic roof tile by Wienerberger |
| 8. Facade | finished with silicone plaster, elvation decorations in the form of stone tiles and decorative wooden elements were used. pedestal clad with stone tiles |
| 9. Windows and doors | wooden |
| 10. Type of heating | gas boiler |
| 11. Ventilation | gravitational |
Ground floor
| Usable area | 96,53 m2 |
| 1. Lobby | 4,82 m2 |
| 2. Hall | 9,5 m2 |
| 3. Kitchen | 21,98 m2 |
| 4. Living room | 40,5 m2 |
| 5. Office | 13,87 m2 |
| 6. Bathroom | 5,86 m2 |
| 7. Storeroom | 2,69 m2 |
| 8. Boiler room | 4,75 m2 |
| 9. Storeroom 2 | 8,8 m2 |
| 10. Storeroom 3 | 8,65 m2 |
| 11. Garage | 39,87 m2 |
Attic
| Usable area | 76,49 (110,76) m2 |
| 1. Hall | (12,48) 12,48 m2 |
| 2. Bedroom | (22,15) 17,31 m2 |
| 3. Wardrobe | (8,62) 3,8 m2 |
| 4. Bedroom 2 | (23,56) 15,19 m2 |
| 5. Bedroom 3 | (17,22) 14,6 m2 |
| 6. Wardrobe 2 | (10,83) 5,41 m2 |
| 7. Bathroom | (11,34) 6,4 m2 |
| 8. Laundry room | (4,56) 1,3 m2 |
| 9. Attic | (9,43) 3,68 m2 |
| 10. Attic 2 | (41,68) 19,84 m2 |
What does the project contain?
Finished project is a documentation, consisting of 3 copies of architectural and construction design and technical design. It is made by authorized designers in accordance with the current rules of construction art and the latest provisions of the Construction Law.
