See Mirror image
One-story house in modern style with usable area 253,08 m2. House with a large garage. Minimum size of a plot needed for building a house is 31,9x33,95 m.
Author:
mgr inż. arch. LESZEK KALANDYK
| 1. Usable area | 253,08 m² |
| 2. Basement area | 160,77 m² |
| 3. Total surface | 462 m² |
| 4. Building area | 328 m² |
| 5. Net volume | 1307 m³ |
| 6. Gross volume | 2995 m³ |
| 7. Energy for heating | 20,03 kWh/m²*year |
| 8. Building height | 11,1 m |
| 9. Roof angle | 35 ° |
| 10. Roof area | 541 m² |
| 11. Сeiling height | 2,60/3,85 m |
| 12. Minimum plot size | 31,9 x 33,95 m |
| 1. Foundation footings | made of reinforced concrete |
| 2. Foundation walls | made of reinforced concrete of thickness 25 and 30cm |
| 3. Exterior walls | made of hollow bricks Porotherm 30 Dryfix of the firm Wienerberger , thickness 30 cm, insulated with styrofoam Platinum facade, thickness 20 cm |
| 4. Interior walls | made of ceramic hollow bricks Porotherm Dryfix 25, 11.5 by Wienerberger firms |
| 5. Ceiling | made of reinforced concrete, slab-on-grade |
| 6. Roof construction | wooden with steel elements, insulated with 36 cm thick mineral wool by Rockwool company |
| 7. Roofing | Koramic ceramic roof tile by Wienerberger firm |
| 8. Facade | finished with silicone plaster, applied elvation decorations in the form of lining with virgin stone scale |
| 9. Windows and doors | aluminum |
| 10. Type of heating | blow along with mechanical ventilation based on gas kiln, prepare hot water with a heat pump |
| 11. Ventilation | mechanical with recuperation |
Basement
| Usable area | 160,77 m2 |
| 1. Garage | 43,8 m2 |
| 2. Storeroom | 25,5 m2 |
| 3. Laundry room | 17,68 m2 |
| 4. Boiler room | 20,91 m2 |
| 5. Storeroom 2 | 33,7 m2 |
| 6. Storeroom 3 | 10 m2 |
| 7. Restroom | 2,3 m2 |
| 8. Storeroom 4 | 3,48 m2 |
| 9. Corridor | 3,4 m2 |
Ground floor
| Usable area | 253,08 m2 |
| 1. Lobby | 18 m2 |
| 2. Living room | 46,85 m2 |
| 3. Canteen | 17,37 m2 |
| 4. Pantry | 1,61 m2 |
| 5. 2 Pantry | 1,38 m2 |
| 6. Kitchen | 12,37 m2 |
| 7. Home Theater | 25,92 m2 |
| 8. Bedroom | 19,27 m2 |
| 9. Wardrobe | 3,61 m2 |
| 10. Wardrobe 2 | 4,24 m2 |
| 11. Corridor | 7,73 m2 |
| 12. Bathroom | 5,34 m2 |
| 13. Corridor 2 | 4,78 m2 |
| 14. Restroom | 6,43 m2 |
| 15. Sauna | 4,47 m2 |
| 16. Restroom | 1,81 m2 |
| 17. Kitchen | 11,6 m2 |
| 18. Gym | 21,44 m2 |
| 19. Bedroom 2 | 18,35 m2 |
| 20. Wardrobe 3 | 2 m2 |
| 21. Bathroom 2 | 3,77 m2 |
| 22. Bedroom 3 | 14,74 m2 |
-1430x1073.jpg)
-cr-190x96.jpg)
What does the project contain?
Finished project is a documentation, consisting of 3 copies of architectural and construction design and technical design. It is made by authorized designers in accordance with the current rules of construction art and the latest provisions of the Construction Law.
Read more on the What does the project contain?
