See Mirror image
Two storey house in modern style with usable area 208,77 m2. House with a large garage. Minimum size of a plot needed for building a house is 24,2x28,4 m.
Author:
mgr inż. arch. LESZEK KALANDYK
| 1. Usable area | 208,77 m² |
| 2. Area garage | 39,53 m² |
| 3. Total surface | 332,86 m² |
| 4. Building area | 219,48 m² |
| 5. Net volume | 815,04 m³ |
| 6. Gross volume | 886,51 m³ |
| 7. Building height | 7,35 m |
| 8. Roof angle | 1,5 ° |
| 9. Сeiling height | 2,7 m |
| 10. Minimum plot size | 24,2 x 26,9 m |
| 1. Foundation footings | made of reinforced concrete |
| 2. Foundation walls | concrete |
| 3. Exterior walls | Porotherm ceramic hollow brick with a thickness of 30 cm by Wienerberger, lined with Austrotherm EPS FASSADA PREMIUM styrofoam with a thickness of 20 cm |
| 4. Interior walls | Porotherm Profi ceramic hollow bricks by Wienerberger with a thickness of 25 cm |
| 5. Partition walls | Porotherm Profi ceramic hollow bricks by Wienerberger with a thickness of 11.5 cm |
| 6. Ceiling | made of reinforced concrete, monolithic |
| 7. Roof construction | made of reinforced concrete |
| 8. Roofing | roofing felt |
| 9. Facade | plaster - white color, Laminam facade plates |
| 10. Windows and doors | aluminum ones by Aluprof firm |
| 11. Type of heating | heat pump, underfloor heating |
| 12. Ventilation | mechanical with recuperation |
Ground floor
| Usable area | 106,62 m2 |
| 1. Lobby | 7,65 m2 |
| 2. Corridor | 7,43 m2 |
| 3. Canteen | 15,3 m2 |
| 4. Pantry | 3,23 m2 |
| 5. Kitchen | 10,43 m2 |
| 6. Living room | 30,50 m2 |
| 7. Corridor 2 | 4,62 m2 |
| 8. Bathroom | 3,64 m2 |
| 9. Guest room | 12,93 m2 |
| 10. Boiler room | 10,89 m2 |
| 11. Garage | 39,53 m2 |
Floor
| Usable area | 102,15 m2 |
| 1. Corridor | 11,82 m2 |
| 2. Bedroom | 22,04 m2 |
| 3. Wardrobe | 7,34 m2 |
| 4. Bathroom | 13,69 m2 |
| 5. Laundry room | 7,72 m2 |
| 6. Bathroom 2 | 5,4 m2 |
| 7. Room | 17,07 m2 |
| 8. Room 2 | 17,07 m2 |
1-530x300.jpg)
2-530x300.jpg)
3-530x300.jpg)
4-530x300.jpg)
What does the project contain?
Finished project is a documentation, consisting of 3 copies of architectural and construction design and technical design. It is made by authorized designers in accordance with the current rules of construction art and the latest provisions of the Construction Law.
Read more on the What does the project contain?
